Cisco ucs s3260 storage server chassis installation and service guide chapter 1 overview replaceable component locations figure 1 3 replaceable components inside the main chassis top view and rear view 1fan modules four hot swappable each fan module contains two fans.

Cisco ucs s3260 storage server base chassis.

The cisco ucs s3260 server helps you achieve the highest levels of data availability and performance. Overview of cisco ucs s3260 architecture. This section describes the high level organization of the system s management and data architecture in relation to the hardware. Cisco ucs s3260 storage server.

Contains eight redundant hot pluggable fans and a rail kit. It provides dense cost effective storage to address your ever growing data needs. One or two ucs s3260 m5 server nodes. The cisco ucs s3260 storage server figure 1 is a modular high density high availability dual node storage optimized server well suited for service providers enterprises and industry specific environments.

Standard 32 inch depth rack such as the cisco r 42610 rack. Each system i o controller sioc module contains an onboard cmc. The system uses a chassis management controller cmc to manage the server nodes. Pdf complete book 8 7 mb view with adobe reader on a variety of devices.

The drives can be configured with enterprise class redundant array of independent disks raid redundancy or with a pass through host bus adapter hba controller.
